River and lake minimalist sailing Scow PDR



Scow 244

A tiny camper scow for rivers & lakes sailing

- LOA 8' x Beam 4' 1/2"
- SA 4.9 m²
- Weight 60 kg
- Weight full load 280 kg
- Camper for one person ( CE D/1 protected waters )

Full plans in PDF with 3D building guide.

5 1/2 sheets of ACX 1/4 - 6 mm plywood.

Junk sail PDR style scow
Full plans micro river boat

35.00 € Add your pocket cruiser plan



Camper river boat scow



Scow 320 "Camper"

A simple sprit sail scow, which can be set as a tent at night on hoops frames. One main central long keel and two bilge skegs to sit upright.

- LOA 3.20 m x Beam 1.24 m
- SA 4.75 m²
- Weight 70 kg
- Weight full load 300 kg
- Camper for one, daysailer for three ( CE D/3 protected waters )

Full plans in PDF with 3D building guide.

3-1/2 sheets of ACX 5/16 8 mm or 3/8 10 mm plywood.

Sprit sail scow
sailing scow plan DIY

40.00 € Add your pocket cruiser plan



Free jung sail sailboat plan



Scow 420 "Camper" FREE

A simple junk sail minimalist scow. Feature my hinged battens details !

- LOA 4.20 m x Beam 1.24 m
- SA 5.7 m²
- Weight 125 kg
- Weight full load 340 kg
- Camper for two ( CE D/2 protected waters )

Full plans in PDF with 3D building guide.

7 sheets of ACX 3/8 10 mm plywood.

Free plan ! [download]


Pocket sailing scow with a cabin



Scow 420 "Cruiser"

A junk sail scow pocket cruiser with a cockpit and a cabin with two bunks.

- LOA 4.20 m x Beam 1.58 m
- SA 9.65 m²
- Weight 200 kg
- Weight full load 450 kg
- Camper for two, daysailer for three ( CE D/3 protected waters )

Full plans in PDF with 3D building guide and photos.

11 sheets of ACX 3/8 10 mm plywood.

plywood sailboat plansBuild your own sailboat

55.00 € Add your pocket cruiser plan

Inland waters sailboat cruiser with junk sail



Scow 450 "Cruiser"

A junk sail scow pocket cruiser with a cabin with four bunks. More pictures.

- LOA 4.50 m x Beam 1.64 m
- SA 10.6 m²
- Weight 250 kg
- Weight full load 580 kg
- Cruiser for four ( CE D/4 protected waters )

Full plans in PDF with 3D building guide and photos.

14 sheets of ACX 3/8 10 mm plywood.

pocket cruiser sailboatSailboat 3D model

70.00 € Add your pocket cruiser plan

Hinged battens junk sail pocket ship



Naut 400

A tiny pocket cruiser with a cockpit and shelter for two. Virtual 3D tour

- LOA 4.00 m x beam 1.64 m
- SA 9.35 m²
- Weight 150 kg
- Weight full load 400 kg
- Camper for two ( CE D/2 protected waters )

Full plans in PDF with 3D building guide and photos.

8 sheets of ACX 3/8 10 mm plywood.

3D building guideFull sailboat plans

50.00 € Add your pocket cruiser plan

Pocket cruiser for home builder



Naut 420 / Gaffer 420

The classic pocket cruiser concept with my junk sailrig.
A cabin with two bunks, and place for all your stuff, camping stove & toilet.

- LOA 4.20m x beam 1.68m
- SA 9.65 m² junk or gaff rig
- Weight kg
- Weight full load 450 kg
- Cruiser for two, daysailer for three ( CE D/3 protected waters )

Full plans in PDF with 3D building guide and photos.

11 sheets of ACX 3/8 10 mm plywood.

Plywood trailerable sailboatPocket cruiser on ply
Pocket cruiser for home builder

60.00 € Add your pocket cruiser plan


Cruising pocket ship



Naut 450 / Cutter 450

Two plans in one !

A pocket cruiser with a double chines hull. Virtual 3D tour

- LOA 4.50 m x beam 1.80 m
- SA 12 m²
- Weight 295 kg
- Weight full load 580 kg
- Cruiser for three ( CE D/3 protected waters )

One double berth, a single bunk, galley and toilet locker.

Full plans in PDF with 3D building guide and photos.

Classic lumber stringers or stich & glue epoxy assembly method.

14 sheets of ACX 3/8 10 mm plywood.

small cutter sailboatsmall boat plans

85.00 € Add your pocket cruiser plan



trailerable cruising sailboat

Schooner jung sail boat



Naut 575

Stich & glue epoxy assembly method.
Plans with variations : ketch, schooner or sloop, two roof shapes.

A larger pocket ship with a double chines hull. Virtual 3D tour

- LOA 5.75 m x Beam 2.23 m
- SA 18.5 m²
- Weight 600 kg
- Internal ferrociment ballast and daggerboard with lead
- Weight full load 1100 kg
- Cruiser for four, daysailer for five ( CE C/3-D/5 )

Full plans in PDF with 3D building guide.

20 sheets of ACX 3/8 10 mm plywood. et 4 sheets of ACX 1/2 12 mm plywood.

Fiber glass / epoxy on the bottom of the hull.



epoxy wood sailboat plansailboat 3D plans

175.00 € Add your pocket cruiser plan





plywood sharpie plans

plywood epoxy sharpie



Sharpie 470

A cabin with a double bunks, and place for all your stuff, camping.

- LOA 4.70 m x beam 1.64 m
- SA 9.9 m² - bermudian or gaff rig.
- Weight 250 kg
- Weight full load 500 kg
- Cruiser for two, daysailer for 3 ( CE D/3 )

Full plans in PDF with 3D building guide.

10 sheets of ACX 3/8 10 mm plywood. et 1 sheets of ACX 1/4 6 mm plywood.


pocket cruiser sharpie plans
boat building



85.00 €



Jangadbrazilian jangada



Jangada 488

Jangadas are traditional fishing boat on the north coast of Brazil, originally simple log rafts.

The Jangada 488 is a special surf scow, with the choice of a Bermudian or a crab claw rig, barn door or lifting rudder, and optional seating wings. There is enough space to sleep on board.

- LOA 4.93 m x Beam 1.8 m
- SA 11.3 m² de voilure - bermudian or crab claw sail
- Weight 220 kg
- Weight full load 500 kg
- Camper for two, daysailer for three ( CE D/3 protected waters )

Full plans in PDF with 3D building guide.

8 to 12 sheets of ACX 3/8 10 mm plywood.


crab claw sail jangada plan



65.00 € Add your pocket cruiser plan



Outboard motor semi dory



Venezia 525 open

Stich & glue epoxy assembly method.
A classical motor launch on a simple semi-dory hull.

- LOA 5.30 m x Beam 1.81
- Weight 450 kg
- Weight full load 900 kg

- Motor 10/30HP
- Daysailer for five ( CE C/4 et D/5)

Full plans in PDF with 3D building guide.

9 sheets of ACX 3/8 10 mm plywood and 4 sheets of ACX 1/2 12 mm plywood.

classic motor launch

motor boat plans



65.00 € Add your pocket cruiser plan

Venezia 525 Cabin

On the same basis, a motor launch with a shelter cabin.

10 sheets of ACX 3/8 10 mm plywood and 4 sheets of ACX 1/2 12 mm plywood.

cabin motor dory plywood

75.00 € Add your pocket cruiser plan



sport sailboat plans



Naut 350

Stich & glue epoxy assembly method.
A contemporary fast sailing dinghy. The hull shape has been tested in a VPP program.

- LOA 3.5 m x Beam 1.4 m
- Weight 65 kg
- SA 4.7/6 m2, can use a Laser 4.7 rig
- For one adult and a child (CE D/2)

Full plans in PDF with 3D building guide.

6 sheets of ACX 1/5 5 mm plywood.

sailboat skiff plans

racing sailboat plans



50.00 € Add your pocket cruiser plan


plywood epoxy trimaran



Trimaran bras repliables





Triops 620

Stich & glue epoxy assembly method.
A folding trimaran for advanced builder.

- LOA 6.2 m x max beam 4.95 m, 2.1 m fold, 1.85 m unbolt.
- Weight 450 kg
- SA 23 m2, can use a Tornado ou Hobie Cat 21 rig and sails.
- Cruiser for four (CE C3/D4)

PDF A3 plans of the main hull and floats, bulkheads, rudder, leeboards, folding beam, glassfibering with UD or carbon.

26 to 28 sheets of ACX 7/16 6 mm plywood.

folding trimaran plans

plywood multihull plans



225.00 € Add your pocket cruiser plan

plywood trimaran with carbon foils

Triops 620 Foils

Option with foils dagguerboards on a wooden shape

- Easy profil maling
- Dyneema ® control lines
- Modifications on the original plan : carbon fiber & beam geometry

trimarans foils plans
Triops 620 foils

85.00 €





DIY sailing kayak plan



Yakyak 365

Stich & glue epoxy assembly method.
A Sit On Top kayak with a leeboard and sailing option.

Plywood epoxy building on a central backbone and light frames.

- LOA 3.65 m x beam 0.80 m
- Weight 35 kg
- Weight max load 160 kg
- SA 1.56 / 1.82m2.
- For 1/2 persons, one adult + a child or two teenagers (CE D2)

4 sheets of ACX 1/5 5 mm plywood.

Sit on Top kayak plywood

SOT kayak plans

55.00 € Add your pocket cruiser plan

DIY sailing kayak plan



Yakyak 425

Stich & glue epoxy assembly method.
A Sit On Top kayak with a leeboard and sailing option.

Plywood epoxy building on a central backbone and light frames.

- LOA 4.25 m x beam 0.78 m
- Weight 35 kg
- Weight max load 190 kg
- SA 1.82 / 2.2m2.
- For 1/2 persons, one adult + a child or two teenagers (CE D2)

4 sheets of ACX 1/5 5 mm plywood.

kayak plan ply

ply epoxy kayak

65.00 €

kayak trimaran



Yakyak 425 option sport

- 2 asymmetric lateral floats
- box-section beam
- 3.7 m2

1sheets of ACX 1/6 4 mm plywood.


plans de kayak sit on top

15.00 €
